Aluminium Loading Ramps (3000x580x16000kg)

580mm wide x 3000mm long, with a 230mm profile thickness. Featuring a maximum capacity of 16000kg, this is one of our heaviest duty ramps and is ideal for use as an industrial plant ramp or heavy duty commercial ramp. Please note the minimum track width is 300mm.

Custom built sizes are available on request. Price and capacity stated is for the PAIR.

Plant Ramps FAQ's

Length (mm)3000
Width (mm)580
Max. Load Height (mm)900
Weight Per Ramp (kg)66.5
Weight Per Pair (kg)133
Capacity (kg)16000
  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty

4-10 business days delivery*. Items are shipped from the UK to Ireland on DAP Incoterms. This means we do not charge Irish VAT but Irish import VAT of 23%, import duty (on some products) and customs charges will be due. These fees will need to be paid to the courier before or after you receive the goods. Learn more.

€2,450.00
SKU
TRP231/30
Built to Order
Description

One of our two heaviest duty ramps from our standard range. The TRP231 Series core profile thickness is 230mm.
At 580mm these ramps are over half a metre wide, feature a capacity of up to 16000kg and are ideal for use as industrial plant ramps and as heavy duty commercial ramps.

On the TRP231 series the minimum width of tracks/wheels is 300mm.

  • These ramps are available both with and without edges. The default is however without edges
  • Four different connection options available, however the default connection is the rest on connection
  • Custom load heights available
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Quotes for bespoke ramps can be supplied on request
  • Fully TÜV certified

TUV Certification Image

Usage guidelines and safety information for our full vehicle ramp range can be found here.

Details
SKU TRP231/30
Default Connection Rest On Connection
Capacity (kg) 16000
Height of Ramps Profile (mm) 230
Length (mm) 3000
Max Load Height 900
Min. Load Height (mm) 750
Weight per Ramp (kg) 66.5
Weight Per Pair (kg) 133
Width (mm) 580
Minimum Track Width (mm) 300
Maximum Track Width (mm) 480
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 15010
Capacity Wheelbase 1500mm (kg) 16000
Capacity Wheelbase 2000mm (kg) 16000
