TRP105F Series - Milled Surface Ramps for Steel Track - 520mm wide
| SKU | Capacity (kg) | Height of Ramp Profile (mm) | Length (mm) | Max Load Height (mm) | Min. Load Height (mm) | Weight per Ramp (kg) | Weight Per Pair (kg) | Width (mm) | Price |
|---|---|---|---|---|---|---|---|---|---|
| TRP-105F/520/1000 | 29000 | 105 | 1000 | 300 | 150 | 27.5 | 55 | 520 | €1,850.00 |
| TRP-105F/520/1500 | 29000 | 105 | 1500 | 450 | 300 | 38 | 76 | 520 | €2,250.00 |
| TRP-105F/520/2000 | 29000 | 105 | 2000 | 600 | 450 | 49 | 98 | 520 | €2,500.00 |
| TRP-105F/520/2500 | 22000 | 105 | 2500 | 750 | 600 | 59.5 | 119 | 520 | €2,650.00 |
| TRP-105F/520/3000 | 18290 | 105 | 3000 | 900 | 750 | 70 | 140 | 520 | €2,850.00 |
| TRP-105F/520/3500 | 12195 | 105 | 3500 | 1050 | 900 | 80.5 | 161 | 520 | €3,150.00 |
| TRP-105F/520/4000 | 9145 | 105 | 4000 | 1200 | 1050 | 91.5 | 183 | 520 | €3,550.00 |
| TRP-105F/520/4500 | 7315 | 105 | 4500 | 1350 | 1200 | 102 | 204 | 520 | €4,100.00 |
| TRP-105F/520/5000 | 6095 | 105 | 5000 | 1500 | 1350 | 112.5 | 225 | 520 | €4,250.00 |
The TRP105F series profile depths are 105mm deep and in width 520mm and feature a capacity from up to 29,000kg.
Special Surface suitable for rubber tracked and steel tracked machinery avaiable upon request. Ramp on this range only available without edges.
