PAIR of ALUMINIUM RAMPS (105X520X4500 - 7315kg) Standard. Milled surface

520mm wide x 4500mm long, with a 105mm profile thickness. Featuring a maximum capacity of 7,315kg, this heavy duty ramp is ideal for use as a plant ramp, digger ramp and for tele-handlers. Custom built sizes are available on request. Price and capacity stated is for the PAIR.

Plant Ramps FAQ's

Length (mm)4500
Width (mm)520
Max. Load Height (mm)1350
Weight Per Ramp (kg)102
Weight Per Pair (kg)204
Capacity (kg)7315
Product Inquiry
  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • One Year Warranty
€4,416.50 €3,650.00
SKU
TRP-105F/520/4500
Built to Order
Talk to The Ramp People's sales team

Our heaviest duty ramps, designed to carry steel tracked vehicles and equipment. The Ramp People range of steel tracked ramps' core profile thickness is 105mm. Available 520mm wide, these ramps feature no external welds and offer a capacity of up to 29,000kg. They are ideal for use as industrial plant ramps and as heavy duty as commercial ramps.

  • Flat top with no external welds
  • On capacities over 20,000kg only Bottom Hook Connection or Tube Connection possible
  • Custom load heights available
  • Quotes for bespoke ramps can be supplied on request
  • Special 25/30 surface available on request, suitable for when using rubber tracked and steel tracked machinery
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Fully TUV certified

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

SKU TRP-105F/520/4500
Default Connection Rest On Connection
Capacity (kg) 7315
Height of Ramp Profile (mm) 105
Length (mm) 4500
Max Load Height (mm) 1350
Min. Load Height (mm) 1200
Weight per Ramp (kg) 102
Weight Per Pair (kg) 204
Width (mm) 520
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Capacity Wheelbase 1000mm (kg) 5225
Capacity Wheelbase 1500mm (kg) 6095
Capacity Wheelbase 2000mm (kg) 7315
