Profile Height up to 230mm
Our vehicle and loading ramps between the heights 160mm and 230mm feature four different sizes: 160mm, 170mm, 185mm, 200mm and 230mm.
TRP160 Series core profile thickness is 160mm, two widths are available: 480mm and the extra wide 510mm. They feature a capacity of up to 9000kg and are ideal for use as car ramps or lightweight plant ramps.
TRP170 Series core profile thickness is 170mm, available with a width of 510mm. They feature a capacity of up to 10.000kg and are ideal for use as plant ramps and mini digger ramps. See vehicle ramps for a full list of features and options.
TRP186 Series core profile thickness is 185mm, available with a width of 510mm. They feature a capacity of up to 12000kg and are ideal for use as plant ramps and mini digger ramps. See vehicle ramps for a full list of features and options.
TRP201 Series core profile thickness is 200mm, available with a width of 580mm. They feature a capacity of up to 14000kg and are ideal for use as plant ramps, for digger ramps and for tele-handlers.
TRP231 Series core profile thickness is 230mm, available with a width of 580mm. They feature a capacity of up to 16000kg and are ideal for use as plant ramps, for digger ramps and for tele-handlers.
Our heavy duty loading ramps are available with 4 connection options. The standard connection is a rest on connection, perfect for flat bed vehicles and tipper trucks.
Nylon grab handles are available to increase the safe manual handling of the heavy duty ramps, please contact us for a custom quote.
Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks.
