Heavy Duty Truck Ramp 750mm wide x 1000kg Capacity

Single Piece Aluminium Loading Ramp with a capacity from 1000kg and 750mm wide, available in lengths of 2000mm, 2600mm, 3000mm and 3600mm.
  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • One Year Warranty
Description

TRP Truck Ramp Features include:

  • Rest on connection: to fit just rest on your truck and start loading (hook connection also available)
  • Extended connection terminal bridges most bumpers, crash bars and tow bars
  • Optimised ramp weight ensures the ramp stays connected to the truck
  • No vehicle or truck modification required
  • Robot welded for solid, strong and durable construction
  • Lightweight aluminium (type 6005A) for easy handling
  • Fully TUV Certified to 1000kg capacity as standard
  • Angled foot which allows for smooth access onto the truck ramp when using casters or wheels
  • Edges on each side of the ramp to prevent accidentally wheeling off (ramps without edges also available)
  • Lengths from 2600mm to 3600mm available
  • Four different connection options available, however the default connection is the rest on connection
  • Bespoke truck ramps built to any length or width
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement

Heavy Duty Truck Ramp 750mm wide

2000mm

  • Length (mm): 2000
  • Height of Raised Edges (mm): 29
  • Max Load Height (mm): 600
  • Min Load Height (mm): 450
  • External Width (mm): 750
  • Internal Width (mm): 690
  • Weight per ramp (kg): 24
  • Capacity (kg): 1000
  • Height of ramp profile (mm): 65

2600mm

  • Length (mm): 2600
  • Height of Raised Edges (mm): 29
  • Max Load Height (mm): 780
  • Min Load Height (mm): 630
  • External Width (mm): 750
  • Internal Width (mm): 690
  • Weight per ramp (kg): 32
  • Capacity (kg): 1000
  • Height of ramp profile (mm): 85

3000mm

  • Length (mm): 3000
  • Height of Raised Edges (mm): 29
  • Max Load Height (mm): 900
  • Min Load Height (mm): 750
  • External Width (mm): 750
  • Internal Width (mm): 690
  • Weight per ramp (kg): 37
  • Capacity (kg): 1000
  • Ramp Profile Height (mm): 100

3600mm

  • Length (mm): 3600
  • Height of Raised Edges (mm): 29
  • Max Load Height (mm): 1050
  • Min Load Height (mm): 900
  • External Width (mm): 750
  • Internal Width (mm): 690
  • Weight per ramp (kg): 45
  • Capacity (kg): 1000
  • Ramp Profile Height (mm): 115

TUV Certification Image

Usage guidelines and safety information for our full vehicle ramp range can be found here.


Details
SKU TRP-Truck750
Default Connection Rest On Connection
Capacity (kg) 1000
Height of Raised Side (mm) 29
Height of Ramps Profile (mm) 65-115
Length (mm) 2000 - 3600
Max Load Height (mm) 780 - 1050
Weight (kg) 24 - 45
Width (mm) 750
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
