Heavy Duty Truck Ramp 750mm wide x 1000kg Capacity

Single Piece Aluminium Loading Ramp with a capacity from 1000kg and 750mm wide, available in two lengths 3000mm and 3600mm.

Truck and Van Ramps FAQ's

Length (mm)2600 - 3600
Width (mm)750
Max. Load Height (mm)780 - 1050
Weight (kg)32 - 44
Capacity (kg)1000

Got a question?

Product: Heavy Duty Truck Ramp 750mm wide x 1000kg Capacity
SKU: TRP-Truck750

  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • One Year Warranty
€615.00 €500.00
In Stock
Talk to The Ramp People's sales team

TRP Truck Ramp Features include:

  • Rest on connection: to fit just rest on your truck and start loading (hook connection also available)
  • Extended connection terminal bridges most bumpers, crash bars and tow bars
  • Optimised ramp weight ensures the ramp stays connected to the truck
  • No vehicle or truck modification required
  • Robot Welded for solid, strong and durable construction
  • Lightweight aluminium (type 6005A) for easy handling and compliance with Health & Safety Guidelines
  • Fully TUV Certified to 1000kg capacity as standard
  • Tested to 200% loading capacity
  • Angled foot which allows for smooth access onto the truck ramp when using casters or wheels
  • Edges on each side of the ramp to prevent accidentally wheeling off (ramps without edges also available)
  • Lengths from 500mm to 5000mm available
  • Bespoke truck ramps built to any length or width
  • Price Match Guarantee: we will beat any similarly specified truck ramp quotation

Heavy Duty Truck Ramp 750mm wide


  • Length (mm): 3000
  • Height of Raised Edges (mm): 23
  • Max Load Height (mm): 900
  • External Width (mm): 750
  • Internal Width (mm): 690
  • Weight per ramp (kg): 37
  • Capacity (kg): 1000
  • Ramp Profile Height (mm):100


  • Length (mm): 3600
  • Height of Raised Edges (mm): 36
  • Max Load Height (mm): 1050
  • External Width (mm): 750
  • Internal Width (mm): 690
  • Weight per ramp (kg): 44
  • Capacity (kg): 1000
  • Ramp Profile Height (mm):115

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

SKU TRP-Truck750
Default Connection Rest On Connection
Capacity (kg) 1000
Internal Width 690
Length (mm) 2600 - 3600
Weight (kg) 32 - 44
Width (mm) 750
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Mat Type Options GSII Nitrile FR
